Some words, and photo lower V6, crankcase.

iis_iis

Hero member
Location
NSW
If not already aware here, never seen any internals hence this photo from facebook "American Engines" contributor j.


The 1977 Laverda 1000 V6 Prototype stands as one of the most extraordinary and ambitious motorcycles ever created, a bold experiment from a company best known for building rugged parallel twins and powerful triples. Conceived for endurance racing, this V6 machine pushed far beyond anything attempted by mainstream manufacturers at the time. Its debut shocked the motorcycle world, revealing a level of engineering that placed Laverda in direct conceptual competition with major factories such as Honda Motor Co. during one of the most innovative eras of racing development.

At the heart of the prototype was its remarkable 996 cc, liquid-cooled, 90-degree V6 engine—an architecture unheard of in motorcycle racing. The engine featured double overhead camshafts and four valves per cylinder, producing around 140–150 horsepower depending on tune. Even by today’s standards, a compact, high-revving V6 motorcycle engine is a rarity, but in the late 1970s it was revolutionary. Power delivery was exceptionally smooth, and the sound of the six-cylinder layout became one of the most unforgettable aspects of the machine.

The engineering was as daring as the concept. Six Dell’Orto carburetors fed the engine, while a sophisticated cooling system ensured reliability under the extreme conditions of endurance racing. The V6 sat longitudinally in the frame with a shaft-drive transmission, resulting in a long but remarkably well-balanced chassis. Despite its size, the prototype was capable of astonishing straight-line performance, reportedly exceeding 280 km/h (174 mph)—speeds normally associated with racing automobiles of the era rather than motorcycles.

The Laverda V6 made its racing debut at the 1978 Bol d’Or endurance race at Paul Ricard. Although it showed breathtaking speed, the bike proved difficult to manage over long distances, and regulatory pressures soon forced Laverda to withdraw it from competition. The prototype had simply pushed too far ahead of the rulebooks of the time. Its brief appearance, however, left a lasting impression on spectators and competitors alike, who were stunned by its speed, sound, and technical audacity.

Today, the 1977 Laverda 1000 V6 Prototype is remembered as one of the most ambitious racing motorcycles ever built. Only one functional example exists, and it remains a moving piece of engineering art, demonstrated occasionally at historic events where its distinctive V6 wail still captivates crowds. More than a motorcycle, it is a symbol of fearless innovation—proof that during the golden age of experimentation, Laverda dared to dream bigger than almost anyone else.

Copied from American Engines on Facebook.

Clutch design makes me question how you change the clutch without splitting the crank case. Doesn't look possible to me, which would be a crapy design. Also, AFAIK, the gearbox was bolted onto the engine on the Laverda V6

Oh have i missed the obvious, this is not the actual Laverda V6 configuration, Barry?? Rather a concept by software construct, indeed Lothar the inboard clutch is perhaps a clue it is not real, am slowly becoming an old clueless person by the looks of it.... or more quickly than i suspect.... may well be best to delete the thread.... j.

Oh have i missed the obvious, this is not the actual Laverda V6 configuration, Barry?? Rather a concept by software construct, indeed Lothar the inboard clutch is perhaps a clue it is not real, am slowly becoming an old clueless person by the looks of it.... or more quickly than i suspect.... may well be best to delete the thread.... j.
Oh no Jon, I wasn't questioning your post, that does look like an interesting crankcase/transmission layout which may have been used by someone... just that 'American Engines' has that feel of being generated to pique peoples interest with stuff that may or may not be genuine. The text often has the feel of the marketing department's press release about it!

Although I would be happy to have my suspicions proven wrong.

cheers,
bazzee

Am I imagining things, or is the phasing on that phony crank in that phony motor 90-90-90? In other words, it doesn't look at all like they'e 120 degrees apart. And interesting take on a slipper clutch!!!

Oh no Jon, I wasn't questioning your post, that does look like an interesting crankcase/transmission layout which may have been used by someone... just that 'American Engines' has that feel of being generated to pique peoples interest with stuff that may or may not be genuine. The text often has the feel of the marketing department's press release about it!

Although I would be happy to have my suspicions proven wrong.

cheers,
bazzee
On the contrary Barry, am obliged to you for invoking a closer examination of the "photo", the gear box does look like graphics grade "lustre" as i peer at the details with my ever increasing strength eye glass, have 3 different focal length for depth of resolution these days. 300mm 450 mm and further than 450mm.

As an image the lower crank case had many elements we know on the main production motors. However....Quentin is the man, am aligned to your clever spotting of the obvious that was not obvious to me, doff's me Arai to the better man. j

Am I imagining things, or is the phasing on that phony crank in that phony motor 90-90-90? In other words, it doesn't look at all like they'e 120 degrees apart. And interesting take on a slipper clutch!!!
Crank phasing could well be correct for a 90° V6. Looks like a cross-plane V8 crank with one pin lopped off...

Cush drive, not slipper clutch, you're over-thinking Quentin. ;) This damping method was used on most old brit thumpers, can also be found on early Goldwing flat 4s.

The whole thing looks like a mash up of the V6 and a Goldwing...

piet

Were it a real motor, it probably would not have straight cut gears between the crank and clutch as they would make it really noisy. Also the reduction gears are after the clutch when you would want them before the clutch.

The rear main bearing is completely different than the other three bearings? It looks to be a roller bearing and the rest are plain bearings. And finally the crank gear looks be held on with a nut which is not a great idea on a bike making this much power, it should be machined as part of the crank.

The gearbox does not look like you can shift gears as they are all too close to each other and no room for the shifting forks.

And where is the oil pump and what does the big gear on the starter do as it does not mesh with anything?

Last edited:
The back end of the crank looks odd.

Were it a real motor, it probably would not have straight cut gears between the crank and clutch as they would make it really noisy. Also the reduction gears are after the clutch when you would want them before the clutch.

The rear main bearing is completely different than the other three bearings? It looks to be a roller bearing and the rest are plain bearings. And finally the crank gear looks be held on with a nut which is not a great idea on a bike making this much power, it should be machined as part of the crank.

And where is the oil pump and what does the big gear on the starter do as it does not mesh with anything?
V6 was racing-only, so noise reduction definitely not a priority, especially if you get around needing to take up the axial loads of helical gears. Bolt-on gear "needed" for rear main bearing fitment... splash lubed from gearbox? Roller/ball mains were often mixed with plain big ends in many brit twins.

Counter-rotating clutch running at engine speed for maximum effect in regard to torque reaction. IIrc, Honda used the same principle in the Goldwing and Flying Maggot.

Starter engages beneath the big gear, looks like a typical Laverda starter drive train has been "used".

Cog spacing in the gearbox and primary drive is odd, as is the ommission of bearings at input and output shafts.

May be AI generated, but at least not total BS.

piet

You hear, PUN people loving the sound of straight-cut gears, really. Worse than Dry Clutches to me. Horrable howling sound, handleable for racing, but not a pleasant sound.

Nothing AI, it’s a photo Cor Dees took of the lower half of the engine that he made from scratch. Not all bearings in place yet and gearbox/clutch section provisionally attached to the main crankcase.

The clutch certainly is in a very impractical position as we found out after a dyno run during which a water leak occurred, causing water to build up in the sump resulting in clutch plates to rust and lock solid. We needed to remove the whole engine, which basically meant dismantling the entire bike, and the rear section of the engine needed to be split. It was multiple days work to fix it, which did not include fixing the water leak. The only good thing was that most of the clutch components in the V6 are regular 750 items..

Marnix


Attachments

  • IMG_5509.png
    1.4 MB · Views: 26
Oh wow - that has me thinking why the factory fotos show the gearbox as a separate item, obviously not sharing the oil with the engine, please? This looks really weird to me, especially as basically this was a car engine, shrinked down from 2,8 Liters to 1 Liter. A Car engine for sure has the clutch between gearbox and engine I would say - no?

I trust you when you say that this pic is from Cor (and btw - has the info he put together been stored somewhere, please? I could only find outdated links...). Still, it looks a weird setup to me, with the 90° phasing (maybe for avoiding the vibrations a 120° has?) and the clutch/Gearbox setup...

Nothing AI, it’s a photo Cor Dees took of the lower half of the engine that he made from scratch. Not all bearings in place yet and gearbox/clutch section provisionally attached to the main crankcase.

The clutch certainly is in a very impractical position as we found out after a dyno run during which a water leak occurred, causing water to build up in the sump resulting in clutch plates to rust and lock solid. We needed to remove the whole engine, which basically meant dismantling the entire bike, and the rear section of the engine needed to be split. It was multiple days work to fix it, which did not include fixing the water leak. The only good thing was that most of the clutch components in the V6 are regular 750 items..

Marnix
Bit of a surprise, the original photo does seem rather surreal though! Only part that looks really authentic is the starter motor...

Especially the primary reduction gear looks like it interferes with the casing. Gearbox spacings still look odd to me.

What exactly are we seeing in Lothars' pic, Marnix? Seems to be a big adapter plate on the engine that doesn't appear in Cors' photo. Template for shaft/gear spacing perhaps?

piet
